The TIS MFTECO TRMS multifunction tester is a reliable and accurate instrument featuring 2* and 3 wire Loop tests, Auto RCD testing Type A and AC, Insulation and continuity tests.
FEATURES
• 2* & 3 wire loop tests
• Accurate & Reliable "No Trip" testing
• Line / Loop Impedence tests
• Phase-Phase, Phase-Neutral, Phase-PE with 2 wire mode
• TRMS for accurate measurements on noisy and distorted circuits
• LPE/LN with PFC/PSC results displayed on a single test
• New Auto Start Mode "on" or "off" for easy testing
• Dual test buttons for left or right handed use
• Phase to Phase Loop Test
• Full help schematic display
• Large COG graphic LCD display (128x128 pixels)
• Compliant with BSEN 61557-12-3-4-5-6-7 18th Edition
• RCD testing 6mA to 1A
• Automatic RCD test, 0°, 180° x 1 x 5 x ½ with ramp & contact voltage tests
• Auto mode for loop & rcd tests in a single test
• Tripping of general, selective RCD's A, AC, B and 6mA RDC-DD for EVSE Charging Station
• Continuity Test of earth conductors with test current >200mA
• Phase Sequence Measurement
• Insulation test at 50, 100, 250, 500 & 1000V
• Safety compliance with IEC EN 61010-1
• Built in pass / fail levels
• Automatic testing of 3 insulation tests from one connection
• Measurement Category CAT IV 300V
SUPPLIED WITH
Neck Strap & Safety Harness
PR400 remote switch
Test Leads, probes & crocodile clips
6 x AA Alkaline Batteries
Soft Padded Carry Case
12 month calibration certificate
Guarantee upgradeable up to 3 years
GENERAL
IP40 rating
IEC EN 61010-1
BSEN 61557-1-2-3-4-5-6-7, 18th edition
Weight including packaging 2.6KG
*European Patent Pending
EAN Barcode: 5060508211228
